100 Series Braided Stainless Steel Rubber lined Hose -6AN

30th September 2019

$40.25 incl. GST

SKU: AF100-06 Categories: ,


Price is per metre

The Aeroflow 100 series hose is a true double braided stainless hose that uses the highest quality stainless wire available in the world.

  • Constructed with a stainless steel outer braid that resists abrasion and corrosion
  • Combined with a reinforced Chlorinated Polyethylene (CPE) synthetic rubber liner with a nylon inner braid.
  • For use with fuel systems, E85, E10, methanol, oils, lubricants, coolant systems and vacuum applications.
  • Minimum temperature -40°C, Maximum temperature 150°C

NOT RECOMMENDED FOR: Brake systems, Extreme heat areas and use inside passenger compartments (due to permeation). For these applications use 200 series hoses & fittings.

100 Series Hose specifications:

  • AN Size: -6
  • Hose I.D: 11/32″ (8.7mm)
  • Hose O.D: 35/64″ (13.8mm)
  • Operating Pressure: 1000psi
  • Burst Pressure: 6000 psi

Additional information

Weight 400 g
Dimensions 30 × 30 × 5 cm
